Numer produktu : 2764821
Hager Rcbo 1p+n 6ka c-13a 30ma a
RCBO 1P+N 6kA C-13A 30mA A Dane techniczne: Krzywa wyzwalania: C Bieguny: 2 bieguny. Nominale obciążenie (in): 13 A Napięcie znamionowe (Un): 230V +10%/-15% Znamionowy prąd wyjściowy (Idn): 30mA Klasa czułości AFrequency:50Hz Znamionowa rozładowanie:6kA w h.t. EN61009-1 Ochrona IP : IP2x zamontowany w obudowie Temperatura :30°C w h.t. EN61009-1 Stopień zanieczyszczenia :2 w h.t.EN61009-1
432,00 zł
351,22 zł netto
Koszt wysyłki od 20,00 zł
W magazynie zewnętrznym, czas dostawy 4-5 dni
HPFI / Circuit breaker combination 1P+N 13A/C Product description: HPFI ADA963G / Circuit breaker combination. 1P+N 13A/C The combination circuit breaker is a compact unit that ensures protection against overload, short circuit and ground fault. It protects people and animals from electric shock in residential and commercial buildings. It protects property from fire in case of insulation failure.Technical data:Trip curve: C Poles: 2 poles.The neutral is located on the right side.Rated current (In): 13 ARated voltage (Un): 230V +10%/-15%Rated tripping current (Idn): 30mASensitivity Class AFrequency:50Hz Rated breaking capacity :6kA according to EN61009-1IP protection : IP2x mounted in enclosure.Temperature :30°C according to EN61009-1Pollution degree :2 according to EN61009-1The combination circuit breakers are all with one pole and neutral - in a width of two modules (36mm) Technical specifications: Rated current(A) :13 Trip curve:C Number of poles:1P+NGround fault trip current(mA) :30
Powyższe informacje / specyfikacje są wskazówkami i mogą zostać zmienione przez producenta bez powiadomienia. Z zastrzeżeniem błędów w druku i obrazów orientacyjnych. Niektóre teksty są generowane automatycznie lub tłumaczone maszynowo i mogą posiadać błędy lub mogą być mylące.
