Numer produktu : 2952329
Schneider Electric Tesys gv motor circuit breaker gv2me21 thermal-magnetic 17-23a 9kw@400v icu15ka pushbutton
Schneider Electric TeSys GV2 wyłącznik instalacyjny 3
465,00 zł
378,05 zł netto
Koszt wysyłki od 20,00 zł
W magazynie zewnętrznym, czas dostawy 4-5 dni
Manual and local control, when the motor circuit-breaker is used on its own, and automatic and remote control when combined with a contactor
Motor protection provided by thermal-magnetic devices built into the circuit-breaker
No live parts are accessible to direct finger contact
The addition of an undervoltage trip enables the motor circuit-breaker to be tripped if voltage is lost
The addition of a shunt trip enables remote control of tripping
The control for the open or enclosed motor circuit-breaker can be locked in the “N/C" position using 3 padlocks
Connectors: spring terminal, screw clamp
Motor protection provided by thermal-magnetic devices built into the circuit-breaker
No live parts are accessible to direct finger contact
The addition of an undervoltage trip enables the motor circuit-breaker to be tripped if voltage is lost
The addition of a shunt trip enables remote control of tripping
The control for the open or enclosed motor circuit-breaker can be locked in the “N/C" position using 3 padlocks
Connectors: spring terminal, screw clamp
Producent
Numer produktu
2952329
Model
GV2ME21
Ean
3389110343212
Do strony producenta
Liczba biegunów
3
Stopień ochrony IP
IP20
Kolor produktu
Czarny, Biały
Zakres temperatur (eksploatacja)
-20 - 60 °C
Zakres temperatur (przechowywanie)
-40 - 80 °C
Dopuszczalna wysokość podczas eksploatacji (n.p.m.)
0 - 2000 m
Szerokość produktu
45 mm
Głębokość produktu
78,2 mm
Wysokość produktu
89 mm
Waga produktu
260 g
Certyfikaty zgodności
RoHS
Cechy
Liczba biegunów
3
Stopień ochrony IP
IP20
Kolor produktu
Czarny, Biały
Warunki pracy
Zakres temperatur (eksploatacja)
-20 - 60 °C
Zakres temperatur (przechowywanie)
-40 - 80 °C
Dopuszczalna wysokość podczas eksploatacji (n.p.m.)
0 - 2000 m
Waga i rozmiary
Szerokość produktu
45 mm
Głębokość produktu
78,2 mm
Wysokość produktu
89 mm
Waga produktu
260 g
Szczegóły techniczne
Certyfikaty zgodności
RoHS
Powyższe informacje / specyfikacje są wskazówkami i mogą zostać zmienione przez producenta bez powiadomienia. Z zastrzeżeniem błędów w druku i obrazów orientacyjnych. Niektóre teksty są generowane automatycznie lub tłumaczone maszynowo i mogą posiadać błędy lub mogą być mylące.
