Numer produktu : 3423136

Lindy - transmitter and receiver - video/audio/infrared/serial extender - HDBaseT 2.0

Nadajnik i odbiornik, przedłużacz video/audio/podczerwień/szeregowy, HDBaseT 2.0, do 100 m

5 030,00 zł 4 089,43 zł netto
Koszt wysyłki od 20,00 zł
W magazynie zewnętrznym, czas dostawy 4-5 dni
Ładowarka w zestawie
Charger included

The Lindy 100 m Cat.6 Dual Head HDMI, USB and RS-232 KVM Extender is a powerful, versatile solution for extending and controlling a dual head workstation up to distances of 100 m (328.08 feet) over a single Cat.6 cable using HDBaseT. It's utilization of the HDBaseT 2.0 specification allows for the transmission of audio, video and various control methods with just one connection between the transmitter and receiver units. The use of two HDMI displays at resolutions up to 1920 x 1080 @ 60 Hz and USB HID's in a convenient remote location creates a super effective productivity console. This gives users the ability to fully operate a high-performance PC which is stored in a convenient location, helping to meet the requirements of modern offices as multiple applications can be open and sharing data simultaneously. Up to 7.1 Digital and Stereo analog can be passed through from the source to standalone amplifiers, speakers and headphones to ensure any relevant audible information or data is understood by the user.Serial and Bi-directional IR add to this extender's comprehensive suite of control methods. Source and display devices can be controlled at either point of a configuration using an IR remote control, whilst serial input and control devices can be used at the remote console. In applications which rely heavily on the uptime of source devices such as medical environments or manufacturing, the Lindy 100 m Cat.6 Dual Head KVM extender can be used to ensure PCs or servers can be locked in a secure location to prevent any unauthorized access or tampering of equipment and protect them from major power outages, fires or water leaks. It's reliable HDBaseT connection means users can be confident that control will always be maintained over the source device even in the most demanding environments.

Producent
Numer produktu
3423136
Model
39374
Ean
4002888393744
Do strony producenta
Opis produktu
LINDY - nadajnik i odbiornik - przedłużacz video/audio/podczerwień/szeregowy - HDBaseT 2.0
Rodzaj urządzenia
Przedłużacz video/audio/podczerwień/szeregowy
Typ obudowy
Zewnętrzna
Lokalizacja
Europa, Wielka Brytania, Stany Zjednoczone, Australia
Szybkość transmisji danych
8.92 Gbps
Protokół komunkacyjny danych
HDBaseT 2.0
Maks. zasięg transmisji
100 m

Ogólne

Rodzaj urządzenia
Przedłużacz video/audio/podczerwień/szeregowy
Typ obudowy
Zewnętrzna
Kolor
Czarny
Lokalizacja
Europa, Wielka Brytania, Stany Zjednoczone, Australia

Praca w sieci

Technologia podłączania
Przewodowa
Protokół komunkacyjny danych
HDBaseT 2.0
Szybkość transmisji danych
8.92 Gbps
Maksymalna rozdzielczość
1920 x 1080 @ 60 Hz
Maks. zasięg transmisji
100 m
Wskaźniki statusu
USB, status
Cechy
Obsługuje kanał audio 7.1, metalowa obudowa, przycisk copy EDID
Zgodność z normami
HDCP 1.4

Rozszerzenie / połączenie

Interfejsy
2 x HDMI
4 x USB - Type A
1 x RS-232 (element dwukierunkowy) - DB-9
1 x IR (wyjście) - mini jack
1 x IR (wejście) - mini jack
1 x SPDIF - TOSLINK
1 x wyjście dźwięku - mini jack
1 x mikrofon - mini jack
1 x mini-USB - Type B

Różne

Dołączone akcesoria
8 gumowych stóp
Dołączone przewody
1 x kabel mini-USB do USB - 1 m
2 x kabel odbiornika IR - 1.5 m
2 x kabel nadajnika IR - 1.5 m
Zgodność z normami
RoHS, REACH, FCC Part 15 B, WEEE

Zasilanie

Zasilacz
Adapter mocy zewnętrznej
Ilość zainstalowanych
2
Maksymalna obsługiwana ilość
2

Wymiary i waga

Wymiary (szerokość x głębokość x wysokość) / Waga
Przekaźnik: 15.6 cm x 13 cm x 4.2 cm / 720 g
Odbiornik: 15.6 cm x 13 cm x 4.2 cm / 720 g

Wielkość i waga (ładunek)

Szerokość transportowa
47 cm
Głębokość transportowa
22 cm
Wysokość transportowa
6.7 cm
Waga transportowa
2.5 kg

Parametry środowiska

Minimalna temperatura pracy
0 °C
Maksymalna temperatura pracy
65 °C
Dopuszczalna wilgotność
0–90% (niekondensująca)

Powyższe informacje / specyfikacje są wskazówkami i mogą zostać zmienione przez producenta bez powiadomienia. Z zastrzeżeniem błędów w druku i obrazów orientacyjnych. Niektóre teksty są generowane automatycznie lub tłumaczone maszynowo i mogą posiadać błędy lub mogą być mylące.
