Schneider Electric 24 v led illumi. p.b bod

Lamp pushbutton ZB5AW0B11 24VAC/DC Product description: Pushbuttons, rotary and key switches Harmony Style 5 (Series XB5) plastic Ø 22 mm - Complete units - Paddle pushbutton, black Ø40mm The pushbutton program Harmony style 5 refers to the series of pushbuttons, signal lamps and lamp pushes with plastic front rings. The series model numbers start with XB5 and replace the Ø22 mm XA2-B series. However, the XA2-B series is still used with the XAC pendant switch program and is therefore included in this catalog. See section on pendant switches. Signal lamps and lamp pushes now use Protected LED technology, which provides up to 100,000 hours of maintenance-free operation. Some advantages of the new LEDs compared to traditional incandescent bulbs include: less maintenance no need for bulb testing all colors available (including blue and white) wide voltage range with same light intensity: 12V and 230V (see limits on page 311). Connection can be made either via screws with locking washers, plugs or pins for printed circuit boards.The program consists of:Complete units XB5-AComponents for assembly ZB5-AParts and accessories ZB5-AThe complete units consist of:Flush-mounted buttons flush-mounted buttons with silicone cap raised buttons paddle button double-push buttons emergency stop (push-pull, push-turn and emergency stop with key according to EN418), rotary switch,key switch.Signal lamps (3 types):With built-in LED for BA9s incandescent bulbs direct supplyand transformer.Lamp pushes(5 types):Roundwith built-in LEDfor BA9sincandescent bulbsdirect supplyand transformer.Doublelamp pusheswithbuilt-inLEDandrotaryswitchwithbuilt-inLED.Signs(commonforXB4andXB55series)The signs can be designed bythe user using a design software provided on a diskette.Ø 22 mm timers, sounders and fuse holdersAmong other products from the Harmony style 5 series are:timers from 0 to 9999.9 hours,sounders,80DBfuse holders for5x20mmfuses Technical specifications: Color: WhiteVoltage (V):24VACDCContacts
