Atomos Sumo19 SE
Monitor/rejestrator do streamingu oferuje 19" dotykowy ekran HDR o jasności 1200 nitów z pokryciem DCI-P3, nagrywanie wielowejściowe SDI/HDMI oraz 4-kanałowe przełączanie HD z profesjonalnym dźwiękiem XLR.
Atomos Sumo19 SE to solidny, wszechstronny wyświetlacz video village na plan, stworzony do monitoringu HDR o wysokiej jasności i rejestracji wysokiej jakości, w tym Apple ProRes RAW do 6Kp30, nagrywania 10-bit ProRes/DNxHR do 4Kp60 oraz jednoczesnego nagrywania ISO z wielu wejść.
- Dotykowy ekran HDR 1200 nitów obejmujący gamut barw DCI-P3
- Nagrywanie Apple ProRes RAW przez SDI do 6Kp30
- 10-bit 4:2:2 Apple ProRes lub Avid DNxHR do 4Kp60 przez SDI lub HDMI
- Przełączanie i nagrywanie na żywo 4-kanałowe 1080p60 ISO oraz nagrywanie programu przez 3G-SDI (Level A)
- Dwa pełnowymiarowe zbalansowane wejścia XLR z zasilaniem phantom 48V, wskaźnikami i kontrolą wzmocnienia
Idealny do monitoringu na planie, przełączania i rejestracji dzięki elastycznej łączności oraz zestawowi narzędzi audio/wideo gotowemu do pracy w workflow.
Unlock the full potential of SDI RAW cinema cameras with SUMO 19SE. Preserve the pristine quality of the camera sensor data by recording in Apple ProRes RAW up to:
6Kp30
4Kp60 DCI/UHD
2Kp240 DCI/HD
Alternatively, record in CinemaDNG up to 4Kp30 DCI.
SUMO 19SE is compatible with Sony FS series cameras, Canon C300 MKII/C500, Panasonic EVA-1/Varicam LT, and many more.
10-bit ProRes and DNxHR/HD up to 4Kp60
Video from virtually any camera or digital video source can be recorded via SDI or HDMI. Record up to 10-bit 4:2:2 in Apple ProRes or Avid DNxHR codecs at up to 4Kp60.
With multi-input SDI support, SUMO 19SE can record up to four inputs simultaneously and also supports ProRes LT and DNxHD 36 for extended recording times.
High-Brightness HDR Monitoring
With 1200 nits brightness, a 19-inch 1920 × 1080 display, and 10-bit processing in a rugged chassis, SUMO 19SE is ready for any location.
SDI and HDMI I/O support a wide range of input formats and enable:
4K → HD cross conversion
Signal down-conversion
Live Quad-Channel HD Switching & Recording
Record up to four 1080p60 streams simultaneously (via 3G-SDI Level A only) as separate ISOs, plus a fifth “program” channel of your switched output — while cueing and switching in real time.
Display the mixed output live on set via HDMI or SDI, or connect an HDMI-to-USB capture device to stream the switched feed live.
Switching is asynchronous, eliminating the need for expensive locked sources and allowing use of more affordable cameras that do not support timecode or genlock inputs.
Two Balanced XLR Inputs with 48V
Full-size XLR connectors with 48V phantom power allow connection of two external microphones with balanced analog audio recording and monitoring.
SUMO 19SE includes:
Dedicated audio meters
Gain controls
Frame delay adjustments per channel
Mic- or line-level audio can be seamlessly synchronized with embedded HDMI and SDI audio sources.
Key Specifications
1200-nit HDR touchscreen covering the DCI-P3 color gamut
Record Apple ProRes RAW via SDI up to 6Kp30
4 × HD ISO switching and recording + program recording via 3G-SDI inputs (Level A only)
10-bit 4:2:2 Apple ProRes or Avid DNxHR at up to 4Kp60
Powered via AC or dedicated Battery XLR inputs for continuous external battery operation
BattWing included for mounting V-Lock or Gold Mount batteries
100 × 100 VESA mount, plus 3/8" and 1/4"-20 mounting options
Same rugged and versatile design as SUMO 19 and compatible with the same accessories
In the Box
SUMO 19SE unit
1 × Master Caddy II
1 × BattWing mounting bracket with 4 screws
2 × desktop feet with 4 × 1/4" mounting screws
AC power supply
